Postgresql Master-Slave Replication Setup On EC2

The master-slave database replication is a process of copying (syncing) data from a database on one server (the master) to a database on another server (the slaves) and distributing the read/write request load as per the system requirements. Where the Master is the read/write server and slaves are read-only servers.

In this article, we will use PostgreSQL Streaming Replication to develop a master-slave configuration. But before moving forward, a few questions come to mind:

• What is Streaming Replication?
• Do we have another way of replication?

Streaming Replication

Streaming replication allows a standby (slave) server to stay more up-to-date than is possible with file-based log shipping. The slave connects to the master, which streams WAL records to the slave as they're generated, without waiting for the WAL file to be filled.

Streaming Replication provides the capability to continuously ship and apply Write-Ahead Logging (WAL) records to some number of slave servers in order to keep them current.

Types of Streaming Replication

Asynchronous (default) - As the name suggests, a create/update/delete request on the master server doesn't wait for the completion of the same in the slave server. Which decreases the latency of the requested operation.

Synchronous - Obviously, this type of streaming replication will wait for the operation to be completed in the slave server too. This leads to an increase in the latency of the requested operation.

Logical Replication

We have another type of Replication method in PostgreSQL: Logical Replication.

Logical replication uses a publish and subscribe model with one or more subscribers subscribing to one or more publications on a publisher node. Subscribers pull data from the publications they subscribe to and may subsequently re-publish data to allow cascading replication or more complex configurations.

Read more about Streaming Replication and Logical Replication.

Setup EC2 Instances

Create two instances named as PostgresqlMasterServer and PostgresqlSlaveServer. Keep the Private IPv4, Public IPv4 DNS of each EC2 instance, and the Private key .pem file of the EC2 instance. Following is the example of two EC2 instances with the above-mentioned attributes.

Connect To EC2 Instance Using SSH

Note: Before moving forward in this step, make sure your OS has SSH installed and EC2 Server has Inbound TCP/IP Security Rule enabled for Port 22. SSH uses Port 22 to connect to EC2 Server from a remote machine.

Now connect to the EC2 instance from your local terminal using the below command.

# change the access of .pem file if you are not the root user
Kodeweich@cloud-dev:$ chmod 600 /path_to_pem_file/

# connect to ec2 instance server
# only for Debian based ec2 instance, for other OS replace admin with root user.
Kodeweich@cloud-dev:$ ssh -i /path_to_pem_file/ admin@Public_IPv4_DNS

Maintain two separate terminal windows for PostgresqlMasterServer and PostgresqlSlaveServer. The above operation will be performed for both servers with their .pem file.

Installing PostgreSQL

Now install PostgreSQL on both instances using the below command.

Kodeweich@cloud-dev:$ sudo apt-get update
Kodeweich@cloud-dev:$ sudo apt-get install postgresql postgresql-contrib postgresql-client

By default, both servers will be running on the main cluster. You can check the server status by the below command.

Kodeweich@cloud-dev:$ sudo systemctl status postgresql

If the PostgreSQL server is not running you can run the below commands to enable and start your PostgreSQL server.

Kodeweich@cloud-dev:$ sudo systemctl enable postgresql   # enable server
Kodeweich@cloud-dev:$ sudo systemctl start postgresql    # start server
Kodeweich@cloud-dev:$ pg_lsclusters                       # list all clusters in the system

Note: If you face any error during the setup of the configuration you can check the logs of both servers using the below command:

Kodeweich@cloud-dev:$ less /var/log/postgresql/postgresql-13-main.log
# if you are running another version of postgresql replace 13 with version.

Configure the Master Server

There are four things we have to do on the Master server:

1. Enable Networking

The first thing is to change postgresql.conf. The file can be found in /etc/postgresql/13/main/ of the main cluster. However, if you have no clue where to find postgresql.conf, you can ask PostgreSQL itself to point you to the configuration file.

Here is how it works:

Kodeweich@cloud-dev:$ sudo su - postgres    # logged in to the cluster with postgres user
postgres@ip-172-31-3-162~$ psql postgres    # switch to the default database
postgres=# SHOW config_file;                # printout path of postgresql.conf file
postgres=# \q                               # exit from postgres database

Now open the postgresql.conf file and update the value of listen_addresses.

listen_addresses="172.31.3.162"   # you can add multiple addresses comma separated

2. Create a Replication User

Now create a replication user which will be used for data replication from the master to slaves. (optional but recommended for best practices)

postgres@ip-172-31-3-162~$ psql postgres
postgres=# CREATE USER replication_user WITH password "password_for_user" REPLICATION;

3. Allow Remote Access

Once you have successfully created a user with REPLICATION permission, configure the pg_hba.conf file located in the same location as postgresql.conf file and add the below line in the IPv4 section of the file.

# TYPE  DATABASE        USER            ADDRESS                 METHOD
host    all             replication_user   172.31.6.22/32         md5
# md5 defines the password based authentication for connection from Slaves to Master on initial db sync.

4. Restart the Master Server

Kodeweich@cloud-dev:$ sudo systemctl restart postgresql
# run below command to check whether server running on TCP/IP 172.31.3.162:5432
Kodeweich@cloud-dev:$ netstat -plntu

That's it, your master server has been set up properly. Now let's move toward the slave server.

Configure the Slave Server

The next step is to create the Slave. There are various things we need to do to make this work. The first thing is to make sure that the replica is stopped and that the data directory is empty.

First, make sure the service is stopped:

Kodeweich@cloud-dev:$ sudo systemctl stop postgresql

Then, we need to make sure the data directory of the PostgreSQL main cluster is empty because we are going to sync the Slave Server with the Master Server and the Slave Server will contain the same data in the data directory as the Master Server:

Kodeweich@cloud-dev:$ sudo su - postgres

# change the value 13 as per installed postgresql version
postgres@ip-172-31-6-22~$ cd /etc/postgresql/13/main/

# if above directory is not empty run below commands.
postgres@ip-172-31-6-22~$ cd /etc/postgresql/13/
postgres@ip-172-31-6-22~$ mv main main_backup
postgres@ip-172-31-6-22~$ mkdir main/
postgres@ip-172-31-6-22~$ chmod 700 main/

Initial Data Replication

Note: Before starting this step, make sure that your Master Server has the Inbound rule added in the Security group for the TCP/IP connection of the Slave Server at PORT 5432.

pg_basebackup will connect to the Master Server and simply copy all the data files over. The connection has to be made as replication_user.

• The -D flag defines the destination directory where we want to store the data on the Slave.
• The -R flag automatically configures our Slave for replication. No extra configuration is needed on the secondary server.
• Finally, we created a replication slot. What is the purpose of a replication slot in PostgreSQL? Basically, the primary server is able to recycle the WAL – if it is not needed anymore on the primary. But what if the replica has not consumed it yet? In that case, the replica will fail unless there is a replication slot ensuring that the primary can only recycle the WAL if the replica has fully consumed it.

postgres@ip-172-31-6-22~$ pg_basebackup -h 172.31.3.162 \
-U replication_user \
--checkpoint=fast \
-D /etc/postgresql/13/main/ \
-R \
--slot=some_name -C \

# it will ask for password authentication

postgres@ip-172-31-6-22~$ password: <password_of_replication_user>

Now for confirmation, check whether Initial Data Replication has been set up properly or not. Check the file created in /etc/postgresql/13/main/ and make sure the following changes have been configured in the main folder.

• standby.signal has been created which indicates that this is the Replica (Slave) Server.
• Check the content of postgresql.auto.conf file. It should be configured as below:
• primary_conninfo = 'user=replication_user password=secret host=172.31.3.162 port=5432 sslmode=prefer sslcompression=0 gssencmode=prefer krbsrvname=postgres target_session_attrs=any'

Change the value of listen_addresses in postgresql.conf file. Which will be located in /etc/postgresql/13/main/.

listen_addresses="172.31.6.22"   # you can add multiple addresses comma separated

Starting Slave Server

Now we are ready to start the Slave server. Run the below command:

Kodeweich@cloud-dev:$ sudo systemctl start postgresql

# run below command to check whether server running on TCP/IP 172.31.6.22:5432
Kodeweich@cloud-dev:$ netstat -plntu

Test the Server Setup

In your master server, run the below command to check the connection of the Slave server.

Kodeweich@cloud-dev:$ sudo su - postgres

postgres@ip-172-31-3-162:~$ psql postgres

postgres=# \x   # expanded display on

postgres=# SELECT * FROM pg_stat_replication;

In your slave server, run the below command to check the connection of the Master Server.

Kodeweich@cloud-dev:$ sudo su - postgres
postgres@ip-172-31-6-22:~$ psql postgres

postgres=# \x   # expanded display on
postgres=# SELECT * FROM pg_stat_wal_receiver;

If you do not get any row in the SELECT statement, make sure you have performed the above steps carefully. For an insightful view, you can check the log file.

Now if you perform any CREATE/UPDATE/DELETE query in the Master Server, you will find instant replication of the same query output in the Slave Server too.

Example:

# master server
postgres=# CREATE TABLE userData (id int, name varchar(100));
CREATE TABLE

Now if you check it in your slave server, you will have the same table in the slave server too.

Conclusion

So I hope you have successfully set up your PostgreSQL Master-Slave replication on EC2 Server. If you face any issues during setup, let me know in DM and I will try to help you out.
